Instrument specifications:

• Operation modes:  standard, stress/strain, creep, stress relaxation, dynamic TMA, modulated TMA
• Temperature Range (max):   -150 to 450°C
• Temperature Precision:   + /- 1°C
• Maximum Sample Size – solid:  26 mm (L) x 10 mm (D)
• Maximum Sample Size - film/fiber:   26 mm (L) x 0.5 mm (T) x 4.7 mm (W)
• Measurement Precision:   +/- 0.1 %
• Sensitivity:   15 nm
• Dynamic Baseline Drift:   <1 µm (-100 to 500°C)
• Force Range:   0.001 to 1 N
• Force Resolution:   0.001 N
• Frequency:   0.01 to 2 Hz
• Atmosphere (static or controlled flow): Inert, Oxidizing, or Reactive Gases
